Novastar H9 Video Splicing Processor

NovaStar H9

LED Video Splicing Processor

  • Designed for fine pitch LED displays
  • Support hot swapping of input and output cards
  • Easy maintenance and low failure rate

NovaStar H9 LED Video Splicing Processor

The NovaStar H9 is a powerful video splicing processor. It features a stable hardware architecture and provides various connector modules for personalized configuration.

What is a Video Splicing Processor?

A video splicing processor supports multiple-screen display applications with different resolutions. It helps to process various video input signals and output signals in real-time.

Novastar H9 Video Splicing Processor

Features

  • Two kinds of 4K LED sending cards that can load up to 10,400,000 pixels and 13,000,000 pixels.
  • Multi-capacity configuration on a single card slot.
  • Simple screen configuration using a single card and connector.
  • Online status monitoring of all input and output cards.
  • Hot-swappable input and output cards.
  • RJ45 IP input card supports up to 100 IP camera inputs and input mosaic.
  • Auto decryption of HDCP-encrypted sources.
  • HDR10 and HLG processing.
  • Eye saver mode.
  • Multi-layer display.
  • Support BKG.
  • OSD settings on a single screen and adjustable OSD transparency.
  • HDR and 10-bit video processing.

Application

NovaStar H9 is a powerful video splicing processor that supports multi-layer displays. A single card supports 16 x 2K layers, 8 x DL layers or 4 x 4K layers. All layers support cross-connector output and the layer quality is not reduced.

Novastar H9 Multi-layer Display

60FPS Processing

Support full 60 frame rates per second. Enable smooth playback and processing without delay or frame loss.

Novastar Splicing Processor 60 Frame Rate

Specifications

Input Card

4 x DVI input card

10-bit input source. HDCP 1.4 compliant. Do not support interlaced signal input.

  • Single link
    4 DVI connectors are used as input.
    Support max resolution of 2048 x 1152 @ 60Hz and min resolution of 800 x 600 @ 60Hz.
  • Dual-link
    Connector 1 and 3 are unavailable.
    Support max resolution of 3840 x 1080 @ 60Hz and min resolution of 800 x 600 @ 60Hz.
4 x HDMI input card

Do not support interlaced signal. 10-bit input source.

  • For HDMI 1.3 inputs :
    HDMI 1.3 connectors support min resolution of 800 x 600 @ 60Hz and max resolution of 2048 x 1152 @ 60Hz.
    HDMI 1.4 connectors support min resolution of 800 x 600 @ 60Hz and max resolution of 2048 x 1152 @ 60Hz.
  • For HDMI 1.4 inputs :
    Two HDMI 1.3 connectors are unavailable. Two HDMI 1.4 connectors are used. Support maximum resolution of  3840 x 1080 @ 60Hz. HDCP 1.4 compliant.
1 x HDMI 2.0 + 1 x DP 1.2

The default option is the HDMI 2.0 connector. Can choose to use the DP 1.2 connector. Use only one connector at one time.

  • 1 x HDMI 2.0
    Backward compatible with HDMI 1.3 and HDMI 1.4. HDCP 2.2 compliant.
    Support max resolution of 4096 x 2160 @ 60Hz or 8192 x 1080 @ 60 Hz (forced).
  • 1 x DP 1.2
    Backward compatible with DP 1.1. HDCP 2.2 compliant.
    Support max resolution of 4096 x 2160 @ 60 Hz or 8192 x 1080 @ 60Hz.
2 x RJ45 IP input card

2 x RJ45 Gigabit Ethernet port. Support interlaced signal input.

  • Support protocols : RTSP, GB28181 and ONVIF.
  • H.264 and H.265 formats.
  • Single card decoding.
    4 x 3840×2160 @ 30fps
    16 x 1920×1080 @ 30fps
  • DHCP compliant.
4 x 3G SDI input card

Max resolution of 1920 x 1080 @ 60Hz.

  • Support de-interlacing processing.
  • Backward compatible with HD-SDI and SD-SDI.
  • Support ST-424, ST-292 and SMPTE 259.
2 x CVBS + 2 x VGA
  • VGA
    Support max resolution 1920 x 1080 @ 60Hz.
  • CVBS
    Support PAL and NTSC.
4 x VGA
  • VGA input card
    Support max resolution 1920 x 1080 @ 60Hz.
2 x DP 1.1
  • DP 1.1
    Support max resolution 3840 x 1080 @ 60Hz or 3840 x 2160 @ 30Hz.
  • Support 8-bit and 10-bit inputs.
  • HDCP 1.3 compliant.
H_STD I/O card
  • 2 x COM
    Control devices that adopt RS422/RS485/RS232 protocol.
  • 1 x ETHERNET
    10/100Mbps self-adaptive.
    Support TCP/IP protocol and UDP/IP protocol.
  • 3 x I/O
    Trigger the execution of the function requirements via programming.
    Support input and output modes.
  • 3 x RELAY OUT
  • 3 x IR OUT
1 x 12G SDI input card
  • 12G SDI IN
    Support max resolution 4096 x 2160 @ 60Hz.
    Support de-interlacing processing.
    Do not support input resolution and bit depth settings.
  • 12G SDI LOOP
1 x HDMI 2.0 input card
  • HDMI 2.0
    Support max resolution 4096 x 2160 @ 60Hz or 8192 x 1080 @ 60 Hz (forced).
    HDCP 2.2 compliant.

Output Card

16 x RJ45 + 2 x fiber sending card

LED 4K sending card can load up to 10,400,000 pixels.

  • 16 x RJ45 Gigabit Ethernet output
    8-bit port loads up to 650,000 pixels.
    10-bit port loads up to 320,000 pixels.
  • 2 x OPT output
    Support both SMF and MMF transmission.
20 x RJ45 sending card

LED 4K sending card can load up to 13,000,000 pixels (max 10,752 x 10,752).

  • RJ45 Gigabit Ethernet output
    8-bit port loads up to 650,000 pixels.
    10-bit port loads up to 320,000 pixels.
  • Backup between Ethernet ports.
2 x RJ45 + 1 x HDMI 1.3 preview card
  • RJ45 Gigabit Ethernet output
    Connect to the network for monitoring the inputs and outputs.
  • 1 x HDMI 1.3
    Connect to a monitor for displaying the monitoring information.

Control Card

GENLOCKIN : Accept the Genlock Signal.
LOOP : Loop the Genlock Signal.
ETHERNETFor PC communication.
Connect to PC, switch or router.
For Web Control and NovaLCT screen configuration.
USB 2.0Update the device program.
Import or export the device configuration parameters.
COMIN : Accept the signal from the central control system.
OUT : Loop the signal.

Tech Specs

PowerAC 100V – 240V, 50/60Hz, 10A-5A
Power Consumption450W
Working Temperature0°C to 45°C
Working Humidity0% RH to 80% RH, non-condensing
Dimension482.6mm x 533.0mm x 405.8mm
Net Weight35 kg
Max Input Cards15
Max Input Channels60
Max Output Cards5
Max Loading Capacity65,000,000 pixels
Max Layers80
CertificationsCE, FCC, IC, CCC
