P1.3 Indoor LED Module

P1.3 LED Display Module

Fine Pitch Indoor LED Display

  • Outstanding viewing experience with short viewing distance
  • Narrow pixel pitch of 1.37mm
  • Suitable for indoor applications such as meeting rooms and events

Fine Pixel Pitch 1.3mm

P1.3 fine pitch indoor LED display is one of the most suitable displays for various indoor applications such as airport, conference room, event, seminar and exhibition. High contrast ratio and high brightness.

Vibrant LED Display

P1.3 LED Screen

  • Life-like image display with 1.37mm pixel pitch.
  • P1.3 Indoor LED Display provides a high dynamic color range with accurate color representation.
  • Convenient maintenance and installation.
  • Modular design enables screen size customization.
P1.3 Indoor LED Module
P1.3 Indoor LED Module

Ultra High Contrast

Enhanced image quality with high contrast ratio.

Wide Applications

Suitable for various applications with unique requirements.

Dynamic Image

Vivid image display with high resolution.

High Refresh Rate

High refresh rate helps to deliver smoother-looking motion.

P1.3 LED Display - Specification

ModelP1.3
Pixel Pitch1.37mm
Module Size320 x 160mm
Module Resolution232 x 116 dots
LED Lamp TypeSMD 1010
Brightness450 – 600nits (Adjustable)
Refresh Rate3,840Hz
Greyscale16-bit (281 trillion color) / 65,536 shades per primary color
Driving Method1/29
Min Viewing Distance> 1.3 meter
Pixel Density / m2525,625 dots
Standard PanelMagnesium Alloy
Power Rating (Typ)232W/m2
Max Power Rating580W/m2
MaintenanceFully Front Accessible

P1.3 Fine Pitch Applications

Conference - P1.6 LED Display Application

Large Conference

Meeting Room - P1.5 LED Display Application

Conference Room

Monitoring Center - P1.8 LED Display Application

Monitoring Room
