MCTRL660 is a controller with a single-unit loading capacity of 1920×1200@60Hz. MCTRL600 utilizes UART to cascade and control multiple units. Suitable for a variety of applications, especially rental and fixed installations such as stage broadcasts, monitoring centers, sports arenas, and more.
True hot backup, No flickering, no blackout
One-button upload of settings and parameters
12bit/10bit HDMI input, DVI input
HDMI.DVI loop output for cascading or monitoring
HDCP Blue-ray directly input
8bit video source loading capacity of 1920×1200@60Hz.
12bit video source loading capacity of 1440×900@60Hz
Support for custom resolutions: 3840 pixels of H resolution, 3840 pixels of V resolution
Supports the new generation of NovaStar calibration technology, which is fast and efficient.
Supports resolutions up to 1920×1200@60Hz and downward compatibility.
Multiple controllers can be cascaded.
Supports 18-bit grayscale processing and display.
Manual screen brightness adjustment, which is fast and convenient.
Quick screen configuration without using a computer.
Adopts an innovative architecture to implement smart screen configuration, allowing a screen to be configured within 30 seconds and greatly shortening the stage preparation time.
Adopts NovaStar G4 engine to realize a perfect display image with no flickering or scanning lines, as well as fine quality and good sense of depth.
Supports a variety of video formats, as described in Figure 2-1.
Specification
Model
MCTRL660
Connector Type
Connector Name
Description
Input
DVI IN
1x SL-DVI input connector
Maximum resolution: 1920×1200@60Hz
HDMI IN
1x HDMI 1.3 input connector
Maximum resolution: 1920×1200@60Hz
Output
4x RJ45
4x RJ45 Gigabit Ethernet ports
Capacity per port up to 650,000 pixels
HDMI OUT
1x HDMI 1.3 output connector for cascading
DVI OUT
1x SL-DVI output connector for cascading
Physical Specifications
Dimensions
483.0 mm × 258.1 mm × 55.3 mm
Net weight
3.6 kg Note: It is the weight of a single card only
