NOVASTAR VX1000 LED VIDEO PROCESSOR

SIMPLICITY MEETS POWER

The VX1000 is NovaStar’s new all-in-one controller that integrates video processing and video control into one box.
VX1000 can be widely used in applications such as medium and high-end rental, stage control systems and fine-pitch applications.

SKU: VX1000 Categories: ,
NOVASTAR logo

NOVASTAR VX1000 LED VIDEO PROCESSOR

Key Features

  • 10 Ethernet ports
    • 10 Ethernet ports of output provide 6.5 million pixels of loading capacity
    • A single unit can output a maximum width of 10,240 pixels, with a maximum height of 8,192 pixels
  • High image quality
    • 4K x 1K@60Hz high resolution input, 4K x 1K point to point display
    • 3 x 4K layers, free scaling for each layer
  • Three working modes
    1. Video Controller
    2. Fiber Converter
    3. Bypass
Model VX1000
Loading Capacity 6.5 million pixels
Max Width & Height Max width: 10240 pixels
Max height: 8192 pixels
Layers 3x 4K×1K
Input Connectors 1x 3G-SDI
2x HDMI 1.4
2x DVI(HDMI 1.4)
1x OPT1
Output Connectors 10x Ethernet Ports
1x HDMI1.3
1x HDMI1.4 LOOP
1x DVI LOOP
1x 3G-SDI LOOP
2x OPT
Presets 10
Control Connectors 1x Ethernet Port
2x USB (input & output)
1x GENLOCK (IN & LOOP)

Brand

NOVASTAR
